Incoloy 800HT Incoloy Alloy Seamless Alloy Pipe Uns N08811 W.Nr.1.4876

Product Categories
Shanghai Aboom Metal prodcut co.,ltd
Contact Now

Incoloy 800HT Incoloy Alloy Seamless Alloy Pipe Uns N08811 W.Nr.1.4876

  • 1
  • 2

Brand Name : ABOOM

Model Number : Incoloy 800HT

Certification : EN 10204 Type 3.1

Place of Origin : CHINA

MOQ : 1000kgs

Price : USD Negotiable

Payment Terms : T/T

Supply Ability : 200 TONS PER MONTH

Delivery Time : 7-15dyas

Packaging Details : Standard export packaging

TYPE OF MATERIAL : nickel based alloy

PRODUCT : Incoloy 800HT Nickel Based Alloy Seamless Pipe

STANDARD : ASTM B423

GRADE : Incoloy 800HT / UNS N08811 / W.Nr.1.4876

Manufacturing process : The steel melt shall be refined with AOD or equivalent.

Heat Treatment : shall be supplied in the solution annealed / water quenched condition.

Surface Finish : Descaled, White Pickled, and Passivated Condition

application : Various industrial fields where the operating temperature does not exceed 550 ° C

Contact Now

Incoloy 800HT Incoloy Alloy Seamless Alloy Pipe Uns N08811 W.Nr.1.4876

Incoloy 800HT Nickel Based Alloy Seamless Pipe Uns N08811 W.Nr.1.4876

Material designation: Incoloy 800HT nickel based alloy
US grade: NO8811
German grade: W.Nr.1.4876

Incoloy 800HT (NO8811) nickel based alloy overview:

Incoloy800HT (N08811) is a full-austenitic low-carbon nickel-iron-chromium alloy of the same series as Incoloy 800. The cobalt content in this alloy can be strictly controlled below 0.01%.

Incoloy800HT (N08811) is resistant to many corrosive media. Its higher nickel content makes it resistant to stress corrosion cracking in aqueous corrosion conditions. The high chromium content makes it better resistant to pitting and crevice corrosion cracking. The alloy has good resistance to the corrosion of nitric acid and organic acids, but has limited corrosion resistance in sulfuric acid and hydrochloric acid.
In addition to the possibility of pitting corrosion in halides, it has good corrosion resistance in oxidizing and non-oxidizing salts. It also has good corrosion resistance in water, steam and mixtures of steam, air and carbon dioxide. Used in nitric acid condensers, resistant to nitric acid corrosion, steam heating, good mechanical properties, heating element tubes, good mechanical properties, etc. For applications up to 500 ° C, the alloy is supplied in the annealed state.


Chemical composition of Incoloy 800HT (NO8811) nickel based alloy: see Table-1:
Table-1                                                                                    %

C≤Si≤Mn≤P≤S≤Cr≥Ni≥Mo≥Cu≤
0.06-0.101.01.500.0350.01519.0-23.030.0-35.0--
OthersAl+ TiAl≤Ti≤Fe≤Co≤V≤W≤Nb≤
0.85-1.200.15-0.600.15-0.6039.5----


specification:
Outer diameter Φ6—762mm; wall thickness: 0.5-50mm, maximum length 18000mm
Special specifications are available upon negotiation.
Incoloy 800HT Incoloy Alloy Seamless Alloy Pipe Uns N08811 W.Nr.1.4876
